PSB Alpha P5 Stativhøyttaler (innbytte)

Frequency Response

On Axis @ 0° ±3dB

55-21,000Hz

On Axis @ 0° ±1 1/2dB

65-20,000Hz

Off Axis @ 30° ±1 1/2dB

65-10,000Hz

LF Cutoff -10dB

37Hz

Input Power

Recommended

10 – 90 Watts

Program

60 Watts

Dimensions / Weights / Finish

Size (W x H x D)

6 3/4” x 11 3/8” x 9 1/2”*
(170 x 290 x 240mm)

Weight

10.15lb (4.6kg)/each
22.8lb (10.4kg)/pr

Finish

Black Ash
Walnut

Sensitivity

Anechoic Chamber

87dB

Listening Room

89dB

Impedance

Nominal

8 Ohms

Minimum

4 Ohms

Acoustic Design

Tweeter (Nominal)

3/4” (19mm) Black Anodized Aluminium Dome with Ferrofluid and Neodymium Magnet

Woofer (Nominal)

5 1/4” (133mm) Textured Polypropylene Cone with Rubber Surround

Crossover

2.500Hz, L4

Internal Volume

0.29 cu ft (8.3L)

Design Type

Tuned Port Bass Reflex, 2” (49mm) Rear Port
