Inputs Outputs
- Main Amplifier inBalanced & Unbalanced: 12ch (Exclusive use by a selector switch.)
- Speaker TerminalSPKT-1+
- Number of Speaker Terminals 12
- Bi-Amp Drive /BTL DriveYes / Yes
- Level MeterYes
- ChassisCopper Plated
Multi-Room CI
- RS232 ControlYes
- IR Flasher InYes
- Marantz Remote BusYes
- DC Trigger Input/ Output1 / 1
Specifications
- Number of poweramps12
- Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL200W / 400W
- Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal400W
- Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal200W
General
- Front DisplayLevel Meter
- Auto Power OffYes
- Metal Front PanelYes
- Power Consumption400W
- Power Consumption, No-Sound110W
- Standby Consumption0.2W
- Maximum Dimensions (W × D × H)17.4 × 17.4 × 7.5 in.
- Weight39.7 lbs
-
What's in the boxMain unit, quick start guide,
AC cord,Amp control cable,
Remote control cable,
SP terminal wrench
