MEN220 er romkorreksjonsløsning med Custom-EQ og 2-veis crossover-funksjon i ett brukervennlig komponent.
-
- 0.002% from 20Hz to 20,000Hz
-
- Maximum Input Voltage
- 4.5V Unbalanced and Balanced (Preamp-Power Amp)
2.25V Unbalanced and Balanced (Processor Loop)
-
- Maximum Output Voltage
- 4.5V Unbalanced and Balanced (Preamp-Power Amp)
2.25V Unbalanced and Balanced (Processor Loop)
-
- Signal To Noise Ratio (A-Weighted)
- 100dB
-
- Input Impedance
- 10K ohms Unbalanced and Balanced
-
- Voltage Gain
- 0dB
-
- Output Impedance
- 50 ohms
-
- Crossover Filter Types, Order and Slope
- Butterworth, 1st order, 6 dB/octave
Butterworth, 2nd order, 12 dB/octave
Butterworth, 4th order, 24 dB/octave
Linkwitz-Riley, 2nd order, 12 dB/octave
Linkwitz-Riley, 4th order, 24 dB/octave
Linkwitz-Riley, 8th order, 48 dB/octave
